TOYOMELT™ TM Series
- Product features
- Application example
- TOYOMELT™ TM Series main products list
- Reactive hot-melt (PUR-HM) TOYOMELT™ UM Series
Product features
Wide range of lineups to meet various demands
Both for back glue and for side glue are available. In addition, we have a wide range of product lineups to meet your requirements, including general-purpose, strong adhesive, and low-temperature coating types, and they are used by many customers in the Bookbinding market.
Environmental friendly recyclable hot-melt
Products for back glue meet the "difficult-to-tear test" and fall under the rank A of the "Guidelines for Producing Printed Matter Compatible with Recycling" defined by the Japan Printing Industry Association. This environmentally friendly hot-melts is recyclable.
Application example
Bookbinding applications (back glue and side glue)
TOYOMELT™ TM Series main products list
| Product name | Applications | Softening point | Open time (seconds) | Characteristics |
|---|---|---|---|---|
| TM-2602 | Back glue | 107 | 10 s to 12 s | General purpose type, low generation of oil smoke |
| TM-2780 | Back glue | 104 | 8 s to 9 s | Excellent resistance to solvents and peeling of cover paper |
| TM-2486 | Back glue | 93 | 8 s to 9 s | Excellent hue change over time (good heat resistant hue) |
| TM-894 | Side glue | 89 | 14 s to 16 s | General-purpose type, yarn pulling reduction |
In addition to the above products, there are a wide range of lineups depending on the application and coating environmental.
Reactive hot-melt (PUR-HM) TOYOMELT™ UM Series
Reactive hot-melt (PUR-HM) specialized for adhesives for bookbinding back glue TOYOMELT™ UM series is also available.
Reactive hot-melts is a adhesives that chemically reacts with moisture in the air and paper after being heated and dissolved, and then hardens. Compared to conventional EVA-based hot-melts's adhesives, it has a strong adhesive strength, excellent spreadability, heat and cold resistance which makes it possible to make books that open well to the knod side, that are durable and long lasting.
TOYOMELT™UM Series Main Products List
| Product name | Appearance | Viscosity 125℃ (mPa・S) | Set time | Solidification rate | Residual MDI (%) | Applications/features |
|---|---|---|---|---|---|---|
| UM-7032 | Milky white | 7100 | 20～22 | 4 min 15 s | ＜1 | For bookbinding/MDI reduction product |
| UM-7335B | Yellow | 7300 | 26～28 | 4 min 45 s | 2~3 | For bookbinding |
In addition to the products listed above, we have a wide range of products with different adhesion strengths depending on the type of paper base material and application.
